Feature:
- Adopt a 48KHz sampling rate, clear and bright sound, better than the CD sound quality.
- Using advanced processing chip architecture and unique processing algorithm, the microphone power-on connection time only takes 5 seconds.
- Support intelligent detection of faults, prompting users of AP faults, host communication faults, and low signal strength.
- Support charging through Type-C port, support 18W fast charging, with smart indicator status.
- Support setting SSID function through UI.
- Support Chinese and English language switching, and uniformly set through PC software.
- The chairman unit has a speech timing function. When the timing speech function is turned on, the chairman unit is not restricted.
- With voice control function, the microphone can be turned on intelligently. Support adjusting the sensitivity of the voice control and setting the closing time through the software.
- Support sign-in function, set and initiate through PC software.
- Support conference voting function, support five-key voting, three-key voting function, flexible and convenient.
- Adopt 128-bit AES encryption technology, support WPA/WPA2 wireless security technology, prevent eavesdropping and unauthorized access, and provide higher confidentiality of the conference system.
- Using wireless transmission technology, it only takes very little time for venue layout to carry out activities.
- The chairman has a priority function to turn off all speaking delegate microphones.
- Adopt a 4.3-inch full-color touch screen.
- Equipped with a 3.5mm headphone jack for connecting an external microphone.
- Built-in lithium battery, the battery capacity supports 14 hours of continuous speech.
Product Detail
Model | TS-W310/ TS-W310A |
Microphone type | Cardioid directional electret microphone |
Frequency response | 80Hz~16KHz |
Sensitivity | -41±1.5dB (0dB=1V/Pa,at 1KHz) |
Microphone input impedance | 680Ω |
Max SPL | 120dB |
SNR | >80dB(A) |
Crosstalk | >70dB |
Dynamic range | >80dB |
THD | <0.1% |
Maximum power consumption | 3W |
Power supply | 18650 lithium battery |
Charging method | Connect the charging box through the Type-C interface |
Colour | Graphite gray |
Sign-in function | Touch screen sign in |
Display screen | IPS screen |
Dimension | 140x136x49mm |
Installation method | Desktop |
Wireless frequency range | 5.15~5.85GHz |
Battery capacity | 9600mAh |
Microphone pole | 380mm |
Weight | 0.9kg |
Working hour in speech mode | 13 hours |
Working hour in mixed mode | 14 hours |
